Toyota YARIS 警示铭牌(车外和车内) — Figure 7403
Toyota YARIS EPC diagram 7403, 警示铭牌(车外和车内), with 3 images and 15 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 11282B | Load testing warning labels | 11282-74010 |
| 11283B | Leak Detection Pump Information Label | 11294-28010 |
| 11296C | Engine maintenance information label | 11296-27020 |
| 11298B | Emission Control Information Label | 11298-21110 · 11298-21120 · 11298-21121 · 11298-21122 · 11298-21123 · 11298-21124 |
| 17792C | Engine vacuum hose information label | 17792-21070 |
| 74511F | Nameplate (laser identification label) | 74514-33010 · 74514-33020 |
| 74515A | Anti-theft warning nameplate | 74515-14010 |
| 74529 | Child safety or child restraint lock warning nameplate | 69339-12010 |
| 74541E | Small spare tire warning plate | 42668-14010 |
| 74596A | Side air bag warning label | 74596-12020 · 74596-53010 |
| 74599B | Driver and passenger air bag information labels | 74599-48020 |
| 74751 | tire pressure information label | 42661-52550 · 42661-52551 · 42661-52552 · 42661-52560 · 42661-52561 · 42661-52562 |
| 87529B | Cabin filter information label | 87529-50010 |
| 88723E | Cooler maintenance warning label | 88723-20081 |
| 88723J | Cooler No. 2 maintenance warning label | 88723-52060 |
