Toyota YARIS 侧防护条 — Figure 7503
Toyota YARIS EPC diagram 7503, 侧防护条, with 2 images and 48 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 53851K | Right front fender outer panel pad | 53851-BZ190 |
| 53852D | Left front fender exterior panel pad | 53851-BZ190 |
| 61681G | Right rear fender external panel | 61061-BZ160 |
| 61682G | Left rear fender external panel | 61062-BZ140 |
| 61783J | No. 2 rear fender outer panel pad | 61784-BZ070 |
| 61783K | Rear fender right side external panel pad | 61783-BZ170 |
| 61783L | Rear fender left side outer panel pad | 61783-BZ170 |
| 61784E | No. 2 rear fender outer panel pad | 61784-BZ070 |
| 65631A | Right rear wheel house front panel | 65631-BZ070 |
| 65632A | Left rear wheel house front panel | 65632-BZ070 |
| 75073 | Right front door outer lower protective strip sub-assembly | 75073-BZ120 |
| 75074 | Left front door outer lower protective strip sub-assembly | 75074-BZ120 |
| 75077 | Right rear door outer lower protective strip sub-assembly | 75077-BZ100 |
| 75078 | Left rear door outer lower protective strip sub-assembly | 75078-BZ100 |
| 75395A | No. 1 outer protective strip clip | 90044-67500 |
| 75395G | No. 1 outer protective strip clip | 90467-07230 |
| 75395H | No. 1 outer protective strip clip | 90044-67500 |
| 75395J | No. 1 outer protective strip clip | 90044-67500 |
| 75396 | No. 2 outer protective strip clip | 90044-67500 |
| 75396D | No. 2 outer protective strip clip | 90044-67500 |
| 75396E | No. 2 outer protective strip clip | 90044-67500 |
| 75396F | No. 2 outer protective strip clip | 90467-07230 |
| 75397A | No. 3 outer protective strip clip | 90044-67500 |
| 75397D | No. 3 outer protective strip clip | 90044-67500 |
| 75551 | Drainage groove side decorative strip on the right side of the roof | 75551-BZ360 |
| 75552 | Drainage groove side decorative strip on the left side of the roof | 75552-BZ350 |
| 75561A | Roof drain channel side decorative strip clip | 75561-33030 |
| 75561E | Drainage groove side decorative strip clip on the left side of the roof | 75561-33030 |
| 75601A | Right front fender protection strip sub-assembly | 75601-BZ140 |
| 75602A | Left front fender protection strip sub-assembly | 75602-BZ140 |
| 75768B | Left rear door protective strip lining | 75798-BZ060 |
| 75787A | Right front door outer protective strip lining | 75794-BZ060 |
| 75788A | Left front door outer protective strip lining | 75793-BZ060 |
| 75793 | Front door outer upper protective strip lining | 75793-BZ060 |
| 75794 | Front door outer rear protective strip lining | 75794-BZ060 |
| 75797 | Rear door outer upper protective strip lining | 75797-BZ060 |
| 75797C | Rear door outer upper protective strip lining | 75797-BZ060 |
| 75798 | Rear door outer rear protective strip lining | 75798-BZ060 |
| 75866A | Door sill panel protective strip fixings | 76924-12040 |
| 75866D | Door sill panel protective strip fixings | 76924-12040 |
| 75867A | Door sill panel protective strip clip | 9004A-46403 |
| 75867C | Door sill panel protective strip clip | 9004A-46403 |
| 76901A | Right fender sub-assembly | 76901-BZ290 |
| 76902A | Left fender sub-assembly | 76902-BZ290 |
| 76921A | No. 1 side fender protection strip | 76921-BZ380 |
| 76921D | No. 1 side fender protection strip | 76921-BZ380 |
| 76922C | Side fender No. 2 protective strip | 76922-BZ150 |
| 76922H | Side fender No. 2 protective strip | 76922-BZ150 |
