Toyota YARIS 喇叭 — Figure 8611
Toyota YARIS EPC diagram 8611, 喇叭, with 1 images and 5 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 86510 | tweeter assembly | 86510-BZ300 · 86510-BZ400 · 86510-BZ490 · 86510-BZ520 |
| 86510A | Alarm horn assembly | 86520-BZ250 |
| 86520 | Subwoofer assembly | 86520-BZ170 · 86520-BZ440 |
| 86570 | Vehicle intrusion speaker assembly | 86570-B1020 |
| 86572 | vehicle hacking speaker controller | 86580-B1020 |
