Toyota YARIS 收音机、放大器和冷凝器 — Figure 8601

Toyota YARIS EPC diagram 8601, 收音机、放大器和冷凝器, with 2 images and 10 PNC and OE references.

Toyota YARIS 收音机、放大器和冷凝器 EPC diagram — 862497B
收音机、放大器和冷凝器 — 862497B (200508 – 999999)
Toyota YARIS 收音机、放大器和冷凝器 EPC diagram — 863587C
收音机、放大器和冷凝器 — 863587C (200508 – 999999)

PNC and OE references

PNCPart nameOE numbers
86011Aradio settings phase modulator90980-04141
86011Qradio settings phase modulator90980-04148
86120Radio assembly00000-00000 · 86120-52470 · 86120-52471 · 86120-52560 · 86120-52630 · 86120-52660 · 86120-52A40
86190CStereo socket connector assembly No. 186190-52040
86211No. 1 radio bracket86211-52190
86212No. 2 radio bracket86212-52200
86221Aradio panel86221-52060
86221Dradio panel86221-52050
86250amplifier loudspeaker assembly86250-52030
86730CTelephone amplifier assembly86730-52020
