Toyota YARIS 后门锁和后门把手 — Figure 6706
Toyota YARIS EPC diagram 6706, 后门锁和后门把手, with 1 images and 19 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 69130 | Right rear door lock actuator assembly | 69130-0D010 · 69130-0D011 · 69130-52060 |
| 69140 | Left rear door lock actuator assembly | 69140-0D010 · 69140-0D011 · 69140-52060 |
| 69230 | Right rear door outer handle assembly | 69230-0D010 · 69230-0D900 |
| 69230B | Cushion pad (for rear door outer handle) | 90080-54028 |
| 69240 | Left rear door outer handle assembly | 69240-0D010 · 69240-0D900 |
| 69330 | Right rear door door lock assembly | 69330-0D010 · 69330-0D011 · 69330-0D020 · 69330-0D021 · 69330-52100 |
| 69340 | Left rear door lock assembly | 69340-0D010 · 69340-0D011 · 69340-0D020 · 69340-0D021 · 69340-52100 |
| 69393A | Right rear door lock outer cover | 69393-0D010 |
| 69394 | Left rear door lock outer cover | 69394-0D010 |
| 69410B | Rear door lock plate assembly | 69410-0D010 |
| 69715 | Right rear door No. 2 lock control link | 69715-0D010 |
| 69716 | Left rear door No. 2 lock control link | 69716-0D010 |
| 69730D | Right rear door lock remote control cable assembly | 69730-0D010 · 69730-52010 |
| 69736D | Rear door locking link guide block | 69736-12130 |
| 69737 | Right rear door inner locking link | 69737-0D010 |
| 69738 | Left rear door inner locking link | 69738-0D010 |
| 69740D | Left rear door lock remote control cable assembly | 69730-0D010 · 69730-52010 |
| 69749B | Rear door lock link clamp | 69749-32040 |
| 69753A | Door lock control right angle lever | 69753-10010 |
