Toyota RAV4 蓄电池和蓄电池电缆 — Figure 8201
Toyota RAV4 EPC diagram 8201, 蓄电池和蓄电池电缆, with 2 images and 8 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 28800A | battery positive terminal | 90982-05065 |
| 28800J | battery negative terminal | 90982-06070 |
| 82610G | ENSEMBLE BLOC, FUSIBLE | 82610-0R010 |
| 82621B | Fuse cover | 82621-30010 |
| G3834 | Service plug handle | G3834-0R010 |
| G9280 | Electric vehicle battery assembly | G9280-0R011 · G9280-0R012 |
| G9289G | JOINT, BATTERIE | G9289-0R010 |
| G92T7 | No. 1 HV battery bus box cover | G92T7-0R010 |
