Toyota RAV4 battery holder — Figure 7454
Toyota RAV4 EPC diagram 7454, battery holder, with 1 images and 8 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 74404A | Battery clip sub-assembly | 74404-42030 |
| 74404B | Battery clip sub-assembly | 74404-42120 · 74404-42121 · 74404-42130 · 74404-42131 · 74404-42140 · 74404-42141 |
| 74407A | Battery clamp bolt sub-assembly | 74407-42010 |
| 74431 | battery tray | 74431-42020 · 74431-42050 · 74431-42051 |
| 74451B | Battery clamp bolt | 74451-42010 |
| 74453 | battery holder bracket | 74454-42010 |
| 74461 | battery cover | 74461-42030 |
| 74486 | Battery clip lower bracket | 74486-42010 |
