Toyota RAV4 喇叭 — Figure 8611
Toyota RAV4 EPC diagram 8611, 喇叭, with 2 images and 4 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 86510 | tweeter assembly | 86510-20280 · 86510-22270 |
| 86520 | Subwoofer assembly | 86520-20300 · 86520-22260 |
| 86570 | Vehicle intrusion speaker assembly | 86570-42020 |
| 86572 | vehicle hacking speaker controller | 86572-42020 |
