Toyota RAV4 warning nameplate — Figure 7455
Toyota RAV4 EPC diagram 7455, warning nameplate, with 4 images and 23 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 11282B | Load testing warning labels | 11282-21010 · 11282-74010 |
| 11285A | Coolant System Caution Labels | 11285-37060 |
| 11291B | PLAQUE INDICATRICE DE MOTEUR | 11291-36040 |
| 11293D | engine warning label | 11293-36070 |
| 11298B | Emission Control Information Label | 11298-36210 · 11298-36211 · 11298-36260 · 11298-36430 · 11298-36431 · 11298-36432 · 11298-36450 · 11298-36451 · 11298-36452 |
| 16793E | ETIQUETTE, PRECAUTION VENT REFROIDISSEMENT | 16793-31040 · 16793-36030 · 16793-36050 |
| 28897B | ETIQUETTE, AVERTISSEMENT DE BATTERIE, NO.1 | 28897-36010 |
| 28897C | ETIQUETTE, AVERTISSEMENT DE BATTERIE, NO.2 | 28897-36020 |
| 41991A | warning nameplate | 41992-42030 |
| 41992 | Differential attention label | 41992-48020 |
| 69339A | Child Restraint Lock Warning Nameplate | 69339-33040 |
| 74511F | Nameplate (laser identification label) | 74511-2B300 · 74514-47010 · 74514-48020 |
| 74528B | Back door warning label | 74528-42010 · 74528-42011 |
| 74541B | Small spare tire warning plate | 42668-42020 · 42668-42030 · 42668-52020 |
| 74541E | Small spare tire warning plate | 42668-42010 |
| 74559A | Fuel warning plate | 74559-14050 · 74559-20140 |
| 74569A | Vehicle information plate | 74569-48010 |
| 74596A | Side air bag warning label | 74596-53011 · 74596-53012 · 74596-74020 · 74596-78010 |
| 74599D | Driver and passenger air bag information labels | 74599-48020 |
| 74751 | tire pressure information label | 42661-42810 |
| 88723E | Cooler maintenance warning label | 88723-30210 · 88723-42080 |
| G9275 | No. 1 battery warning label | G9275-48050 |
| G92A1 | HV coolant system information label | G92A1-76010 |
