Toyota RAV4 accelerator pedal connecting rod — Figure 7851
Toyota RAV4 EPC diagram 7851, accelerator pedal connecting rod, with 2 images and 6 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 78110A | Spring (for accelerator pedal lever) | 90959-03292 |
| 78110C | Bushing (for accelerator pedal lever) | 90386-08063 |
| 78120G | Accelerator pedal lever assembly | 78010-42020 · 78120-42110 |
| 78150B | Accelerator pedal automatic transmission cable assembly | 78150-42030 |
| 78180P | Accelerator pedal control cable assembly | 78180-42100 · 78180-42110 |
| 78183B | Accelerator pedal control cable clip | 78183-42020 |
