Toyota RAV4 警示铭牌和名称铭牌(发动机) — Figure 1709
Toyota RAV4 EPC diagram 1709, 警示铭牌和名称铭牌(发动机), with 1 images and 8 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 11278 | Engine emission identification plate | 11278-16040 · 11278-16050 |
| 11289 | Spark plug warning nameplate | 11289-20010 · 11289-62020 |
| 11291 | Engine name plate | 11291-74070 |
| 11293B | Adjust specification information label | 11293-74300 |
| 11298 | Emission control information plate | 11298-7A170 · 11298-7A180 · 11298-7A450 · 11298-7A630 |
| 16448 | Radiator warning nameplate | 16448-7A111 |
| 16793 | Fan warning nameplate | 16793-46010 · 16793-74010 · 16793-75010 |
| 17700C | Air filter warning plate (for engine models) | 17791-74010 · 90917-07118 |
