Toyota RAV4 warning nameplate — Figure 7455
Toyota RAV4 EPC diagram 7455, warning nameplate, with 2 images and 15 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 11291B | Engine name plate | 11291-50051 |
| 11293D | engine warning label | 11293-36070 |
| 16793B | Cooling fan information label | 16793-36030 |
| 41992 | Differential attention label | 41992-0R020 |
| 69339C | Child Restraint Information Label | 69339-06080 |
| 74515C | Anti-theft warning information label | 74515-06020 |
| 74528B | Back door warning label | 74528-0R030 · 74528-0R031 |
| 74541B | Small spare tire warning plate | 42668-0N010 |
| 74541E | Small spare tire warning plate | 42668-20020 |
| 74559B | fuel information label | 74559-33040 · 74579-0D010 · 74579-26011 |
| 74751 | tire pressure information label | 42661-0R230 · 42661-0R240 · 42661-0R250 |
| 88723H | Cooler maintenance warning label | 88723-07080 · 88723-0R060 · 88723-0R130 |
| G9275 | No. 1 battery warning label | 288A2-F0020 · G9275-07010 |
| G9285E | HV Battery No. 1 Warning Label | G928L-02010 |
| G92A1 | HV coolant system information label | G92A1-76010 |
