Toyota RAV4 车轮和车轮盖 — Figure 4103
Toyota RAV4 EPC diagram 4103, 车轮和车轮盖, with 2 images and 6 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 42601 | spoke wheel | 42611-0R060 · 42611-0R070 · 42611-0R080 · 42611-0R120 |
| 42601A | Spoke wheel (for spare tire) | 42611-0R060 · 42611-0R070 · 42611-0R080 · 42611-0R120 |
| 42601C | Hub nut (for axle) | 90942-01033 · 90942-C1001 |
| 42603 | Wheel hub decorative parts sub-assembly | 42603-42120 · 4260B-42010 |
| 42611G | Valve (for tubeless tires) | 90942-05009 |
| 42611J | Valve (for tubeless spare tire) | 90942-05009 |
