Toyota RAV4 警示铭牌和名称铭牌(发动机) — Figure 1709
Toyota RAV4 EPC diagram 1709, 警示铭牌和名称铭牌(发动机), with 1 images and 7 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 11282A | Load testing warning labels | 11282-74010 |
| 11289 | Spark plug warning nameplate | 11289-28010 |
| 11291 | Engine name plate | 11291-28100 · 11291-28120 |
| 11296B | Engine maintenance information label | 11296-27020 |
| 11298 | Emission control information plate | 11298-28150 · 11298-28200 · 11298-28240 · 11298-28300 · 11298-28360 |
| 16701G | warning label | 16793-46010 |
| 17792 | Engine vacuum hose information plate | 17792-28140 · 17792-28180 |
