Toyota HILUX 空气囊 — Figure 8421
Toyota HILUX EPC diagram 8421, 空气囊, with 1 images and 8 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 89170 | air bag sensor assembly | 89170-35150 · 89170-35170 |
| 89173A | Right front air bag sensor | 89173-39335 · 89173-49405 |
| 89174A | Left front air bag sensor | 89173-39335 · 89173-49405 |
| 89178A | Seat position air bag sensor | 89178-06020 |
| 89833 | Right rear air bag sensor | 89833-35010 |
| 89834 | Left rear air bag sensor | 89834-35010 |
| 89860 | Right side airbag sensor assembly | 89860-35010 |
| 89860A | Left side air bag sensor assembly | 89830-35010 |
