Toyota HILUX 车内灯 — Figure 8121
Toyota HILUX EPC diagram 8121, 车内灯, with 1 images and 16 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 81080K | Armrest box lighting assembly | 81205-35010 |
| 81230 | Door control light assembly | 81230-30140 |
| 81230B | Bulb (for gated lights) | 90981-11020 |
| 81231 | door control lamp shade | 81231-50010 |
| 81240B | Interior light bulb No. 1 | 90981-14011 |
| 81240E | Interior light bulb No. 2 | 90981-14011 |
| 81241 | Interior light cover No. 1 | 81241-33030 |
| 81241A | Interior light cover No. 2 | 81241-33030 |
| 81260 | Glove box light assembly | 81260-33010 |
| 81260B | Light bulb (for glove box) | 90981-11018 |
| 81260C | Light bulb (for reading lamp) | 90084-81002 |
| 81340B | Bulb (for vanity lights) | 90981-14014 |
| 81366C | Interior light switch base | 81366-68010 |
| 81366D | Trunk light switch base | 81366-68010 |
| 81380E | Bulb (for running board lighting) | 90981-11020 |
| 81870D | Lock core lighting assembly | 81870-60030 |
