Toyota HILUX 后雾灯 — Figure 8116
Toyota HILUX EPC diagram 8116, 后雾灯, with 1 images and 3 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 81210C | Rear fog light bulb | 90981-13043 |
| 81210R | Rear fog light assembly | 81580-35010 · 81580-35011 · 81590-35010 · 81590-35011 |
| 81211R | Rear fog light cover | 81581-60100 · 81581-60101 · 81591-60130 · 81591-60131 · 81591-60132 |
