Toyota HILUX 前地板和前地板梁 — Figure 5851
Toyota HILUX EPC diagram 5851, 前地板和前地板梁, with 2 images and 28 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 51081 | Right foot plate No. 1 stay sub-assembly | 51081-35060 |
| 51082 | Left foot plate No. 1 stay sub-assembly | 51082-35060 |
| 51083 | Right pedal sub-assembly | 51083-35160 · 51083-35170 · 51083-35180 |
| 51084 | Left pedal sub-assembly | 51084-35150 · 51084-35160 · 51084-35170 |
| 51759A | Left rear door step panel cover | 51759-35070 · 51759-35080 · 51759-35090 |
| 51773C | Right pedal lining cover | 51773-35060 · 51773-35070 · 51773-35080 |
| 51774C | Left pedal lining cover | 51774-35060 · 51774-35070 · 51774-35080 |
| 51779A | Right rear door step panel cover | 51779-35080 · 51779-35090 · 51779-35100 |
| 51793A | Right footboard bracket No. 1 | 51085-60010 |
| 51794A | Left pedal No. 1 bracket | 51085-60010 |
| 51797 | Right footboard bracket No. 3 | 51797-60080 |
| 51798 | Left footboard No. 3 bracket | 51797-60080 |
| 57051 | Front floor right cross member sub-assembly | 57051-35050 · 57051-35051 |
| 57052 | Front floor left cross member sub-assembly | 57052-35050 · 57052-35051 |
| 57401C | Floor right inner longitudinal beam sub-assembly | 57401-35905 |
| 57402C | Floor left inner longitudinal beam sub-assembly | 57402-35906 |
| 57417 | Front floor lower right reinforcement | 57417-35050 · 57417-35051 |
| 57418 | Front floor lower left reinforcement | 57417-35060 · 57417-35061 |
| 57461B | Center floor No. 1 beam sub-assembly | 57461-35020 |
| 57509 | Front floor center reinforcement sub-assembly | 57509-35010 |
| 58111 | front floor pan | 58111-35420 · 58111-35421 · 58111-35422 |
| 58111B | Welding bolts (for front floor pan) | 90115-06166 |
| 58115A | front floor reinforcement | 58115-35010 · 58115-35011 |
| 58127A | Front cross member to front panel beam right reinforcement | 58127-35010 |
| 58128A | Front cross member to front panel beam left reinforcement | 58128-35010 · 58128-35011 |
| 58171 | Parking brake base reinforcement | 58171-35030 |
| 81380P | Footboard lighting assembly | 81380-35010 · 81780-35010 |
| 81380Q | Footboard lighting assembly | 81380-35010 · 81780-35010 |
