Toyota HILUX warning nameplate — Figure 7455

Toyota HILUX EPC diagram 7455, warning nameplate, with 1 images and 9 PNC and OE references.

Toyota HILUX warning nameplate EPC diagram — 740531A
warning nameplate — 740531A (199511 – 999999)

PNC and OE references

PNCPart nameOE numbers
36369Transfer case information label36369-35370 · 36369-35380 · 36369-35430 · 36369-35440
74529Child safety or child restraint lock warning nameplate69339-12010
74544DTire carrier warning nameplate74544-35080 · 74544-35110
74545BTire Carrier No. 2 Caution Label74545-35020 · 74545-35030
74559AFuel warning plate74559-89101
74563Emission control equipment identification plate74563-26260 · 74563-35140 · 74563-35150 · 74563-35180 · 74563-35190 · 74563-35200 · 74563-60080
74751tire pressure information label42661-35410 · 42661-35411 · 42661-35420 · 42661-35421 · 42661-35480
88723HCooler maintenance warning label88723-20030 · 88733-27010
89176AAir bag deployment information label89176-51010
