Toyota HILUX 警示铭牌和名称铭牌(发动机) — Figure 1709
Toyota HILUX EPC diagram 1709, 警示铭牌和名称铭牌(发动机), with 1 images and 7 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 11288 | Engine system nameplate | 11288-62010 |
| 11289 | Spark plug warning nameplate | 11289-62020 |
| 11291 | Engine name plate | 11291-67010 |
| 11292 | Engine No. 2 name plate | 11292-74130 |
| 11296A | Engine maintenance information label | 11296-30010 · 11296-30011 · 11296-62070 · 11296-62071 · 11296-67020 · 11296-67040 · 11296-67050 · 11296-67051 · 11296-75061 · 11296-75062 |
| 11297B | Engine No. 2 maintenance information label | 11297-30010 |
| 17791 | Maintenance information label | 17791-55010 · 17791-74040 |
