Toyota HILUX 后刮水器 — Figure 8502
Toyota HILUX EPC diagram 8502, 后刮水器, with 1 images and 4 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 85110R | Rear wiper motor assembly | 85130-38020 |
| 85168R | No. 1 rear wiper link pivot nut | 85168-95700 |
| 85169R | No. 1 rear wiper link pivot washer | 85134-38020 |
| 85178R | Nut (for securing rear wiper arm) | 85178-95J00 |
