Toyota HILUX 车轮和车轮盖 — Figure 4103
Toyota HILUX EPC diagram 4103, 车轮和车轮盖, with 3 images and 10 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 42601A | Spoke wheel (for spare tire) | 42601-26250 · 42601-35341 |
| 42601C | Hub nut (for axle) | 90942-01051 · 90942-01061 · 90942-01071 · 90942-01075 · 90942-01082 |
| 42601F | Spoke wheels (for front tires) | 42601-26250 · 42601-35341 |
| 42601R | Spoke wheels (for rear tires) | 42601-26250 · 42601-35341 |
| 42603 | Wheel hub decorative parts sub-assembly | 42603-35061 · 42603-35062 · 42603-35240 · 42603-35241 · 42603-35251 · 42603-35270 · 42603-35271 · 42603-35280 · 42603-35281 · 42603-35300 · 42603-35310 · 42603-35360 · 42603-35510 · 42603-35520 · 42603-35650 · 42603-35660 · 42603-35670 |
| 42611G | Valve (for tubeless tires) | 90942-05009 |
| 42611J | Valve (for tubeless spare tire) | 90942-05009 |
| 42621 | wheel cover | 42621-35220 |
| 42652 | tires | 42605-35110 · 42605-35120 · 42605-35130 · 42605-35131 · 42605-35240 · 42605-35250 · 42605-35270 · 42605-35290 · 42605-35291 · 42605-35300 · 42605-35301 · 42605-35310 · 42605-35320 · 42605-6A050 · 42652-35380 · 42652-35400 · 42652-35430 · 42652-35630 |
| 42652A | Tire (for Spare Wheel) | 42605-35110 · 42605-35120 · 42605-35130 · 42605-35131 · 42605-35250 · 42605-35270 · 42605-35290 · 42605-35291 · 42605-35300 · 42605-35301 · 42605-35310 · 42605-35320 · 42605-6A050 · 42652-35380 · 42652-35400 · 42652-35430 · 42652-35630 |
