Toyota HILUX 警示铭牌和名称铭牌(发动机) — Figure 1709
Toyota HILUX EPC diagram 1709, 警示铭牌和名称铭牌(发动机), with 1 images and 11 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 11278 | Engine emission identification plate | 11278-54020 |
| 11284 | Engine bolt information plate | 11284-54020 · 11284-54040 |
| 11291 | Engine name plate | 11291-35030 · 11291-35040 |
| 11292A | identification tag | 11292-54010 |
| 11293 | Engine warning and engine name plate | 11293-72040 · 11296-54030 · 11296-72060 · 11296-72061 |
| 11296A | Engine maintenance information label | 11296-0K010 · 11296-27020 |
| 11298 | Emission control information plate | 11298-3D210 · 11298-3D430 · 11298-3D640 · 11298-72060 · 11298-72061 |
| 17700C | Air filter warning plate (for engine models) | 17791-35050 · 17791-35090 · 90917-07084 · 90917-07108 |
| 17791 | Maintenance information label | 17791-35070 · 17791-55010 |
| 17792 | Engine vacuum hose information plate | 17792-3D140 · 17792-3D141 · 17792-3D151 · 17792-3D160 · 17792-3D280 · 17792-3D320 · 17792-72210 · 17792-72211 · 17792-72290 · 17792-73251 |
| 74513 | Identification number information label | 74513-35230 |
