Toyota COROLLA 后清洗器 — Figure 8504
Toyota COROLLA EPC diagram 8504, 后清洗器, with 1 images and 13 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 85035R | Rear washer nozzle sub-assembly | 85391-02020 · 85391-12050 |
| 85310R | Rear washer motor assembly | 85330-10280 · 85340-08010 |
| 85330S | Rear washer fluid tank bushing | 90068-32002 |
| 85348R | No. 1 rear washer hose connector | 85317-02300 · 85375-10260 |
| 85348S | No. 1 rear cleaner elbow joint | 85355-20200 · 85375-02260 |
| 85349K | No. 2 rear cleaner elbow joint | 85355-20200 · 85375-02260 |
| 85349P | No. 3 rear cleaner elbow joint | 85355-20200 · 85375-02260 |
| 85372D | Rear washer hose seal | 85372-20040 |
| 85372N | No. 1 rear washer hose (from connector to connector) | 90068-33026 |
| 85372P | No. 2 rear washer hose (from connector to connector) | 90068-59021 |
| 85372Q | No. 3 rear washer hose (from connector to connector) | 90068-59022 |
| 85373R | Rear washer hose (from connector to nozzle) | 90068-33027 |
| 85389C | Cleaner protection device | 85389-12010 |
