Toyota COROLLA 背门锁和背门把手 — Figure 6709
Toyota COROLLA EPC diagram 6709, 背门锁和背门把手, with 1 images and 24 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 64680 | Rear door lock control cable assembly | 64680-01010 |
| 68810C | Back door right hinge assembly | 68810-02010 |
| 68820C | Back door left hinge assembly | 68820-02010 |
| 68930 | Back window right side stay assembly | 68930-02010 · 68930-02011 · 68930-02012 · 68930-02020 · 68930-02021 · 68930-02022 |
| 68940 | Rear window left stay assembly | 68940-02010 · 68940-02011 · 68940-02012 · 68940-02020 · 68940-02021 · 68940-02022 |
| 68945 | Back door right damping stay upper bracket | 68945-12040 |
| 68946 | Rear door left damping strut upper bracket | 68946-12010 |
| 68950C | Back door right support rod assembly | 68950-02050 · 68950-02051 · 68950-02060 · 68950-02061 · 68950-02150 · 68950-02151 · 68950-02160 · 68950-02161 |
| 68952 | Rear door support rod fixing | 68952-32011 |
| 68955C | Rear window right side stay upper bracket | 68955-12060 |
| 68956A | Rear window left side stay upper bracket | 68956-12030 |
| 68960 | Back door left support rod assembly | 68960-02040 · 68960-02041 · 68960-02050 · 68960-02051 · 68960-02140 · 68960-02141 · 68960-02150 · 68960-02151 |
| 68961 | Rear door support rod bolts | 68961-20140 |
| 68961J | Rear window stay bolts | 68961-12060 |
| 68971A | Back door No. 1 support rod seal | 68971-32010 |
| 68972A | Back door No. 2 support rod seal | 68972-32010 |
| 69090 | Rear door outer handle assembly | 69090-01010 |
| 69110A | Rear door lock assembly with motor | 69110-02010 |
| 69150 | Rear door lock actuator assembly | 69150-08010 |
| 69211C | Back door outer handle | 69023-13020 |
| 69350P | ENS. VERR, HAYON, AV COMM PLAFONNIER | 69350-02020 |
| 69370E | Rear window lock assembly | 69370-02010 |
| 69430C | Back door lock assembly | 69410-08020 |
| 69450D | Rear window lock assembly | 69450-01010 |
