Toyota COROLLA 警示铭牌(车外和车内) — Figure 7403
Toyota COROLLA EPC diagram 7403, 警示铭牌(车外和车内), with 1 images and 9 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 73794 | Rear seat belt caution label | 73794-02010 |
| 74515A | Anti-theft warning nameplate | 74515-14010 |
| 74529 | Child safety or child restraint lock warning nameplate | 69339-03010 |
| 74540 | Fuse box warning nameplate | 82683-02010 |
| 74541E | Small spare tire warning plate | 42668-02020 · 42668-02030 |
| 74571A | Label cover protective film | 74571-03020 · 74571-32010 |
| 74596A | Side air bag warning label | 74596-02010 |
| 74751 | tire pressure information label | 42661-02120 · 42661-02130 |
| 88723E | Cooler maintenance warning label | 88723-02050 |
