Toyota COROLLA 警示铭牌和名称铭牌(发动机) — Figure 1709
Toyota COROLLA EPC diagram 1709, 警示铭牌和名称铭牌(发动机), with 1 images and 4 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 11289 | Spark plug warning nameplate | 11289-50010 · 11289-62020 |
| 11298 | Emission control information plate | 11298-22030 · 11298-22031 · 11298-22032 · 11298-22040 · 11298-22041 · 11298-22120 · 11298-22121 |
| 16701G | warning label | 88723-0A050 · 88723-20081 |
| 17792 | Engine vacuum hose information plate | 17792-22010 · 17792-22011 · 17792-22012 |
