Toyota COROLLA 前保险杠及附件 — Figure 5201
Toyota COROLLA EPC diagram 5201, 前保险杠及附件, with 1 images and 15 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 52021 | Front bumper reinforcement sub-assembly | 52021-12160 · 52021-12190 |
| 52115A | Front bumper right side bracket | 52115-12280 |
| 52116A | Front bumper left bracket | 52116-12220 |
| 52117C | Front bumper extension section No. 2 fixing piece | 52117-12150 |
| 52119A | front bumper cover | 52119-1A410 · 52119-1A902 |
| 52121B | Front license plate mounting bracket | 52121-12110 |
| 52521 | Front bumper upper center fixing bracket | 52521-12070 |
| 52525 | Front bumper lower center fixing bracket | 52525-12070 |
| 52526 | Front bumper lower side fixing bracket | 52526-12030 |
| 52527A | Front bumper No. 2 lower center fixing bracket | 52527-12030 |
| 52533 | Front bumper No. 1 fixed frame bracket | 52533-12010 |
| 52535 | Front bumper right side fixing bracket | 52503-12020 |
| 52536 | Front bumper left fixed bracket | 52504-12020 |
| 52611 | front bumper energy absorber | 52611-12120 |
| 52711 | Front bumper protection strip | 52711-12140 · 52711-12150 |
