Toyota COROLLA 警示铭牌(车外和车内) — Figure 7403
Toyota COROLLA EPC diagram 7403, 警示铭牌(车外和车内), with 1 images and 11 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 63299 | Removable shell warning nameplate | 63299-12010 |
| 74517 | Exhaust temperature warning nameplate | 74517-20010 · 74517-20020 · 74517-32010 · 74517-32020 |
| 74518 | Maintenance warning nameplate | 74518-14011 · 74518-22021 |
| 74529 | Child safety or child restraint lock warning nameplate | 69339-20030 |
| 74541 | tire pressure warning plate | 42661-12300 · 42661-12310 · 42661-12410 · 42661-12470 · 42661-12471 · 42661-12500 · 42661-12620 · 42661-12621 · 42661-12630 · 42661-12640 · 42661-13100 · 42661-13110 |
| 74555B | Fuse box warning nameplate | 74555-12020 · 74555-12021 · 74555-12022 |
| 74559A | Fuel warning plate | 74559-14010 · 74559-14030 · 74559-22030 |
| 74562 | Emission control system information plate | 74562-10032 · 74562-12220 · 74562-12242 · 74562-12250 · 74562-12260 · 74562-12270 · 74562-12280 · 74562-12290 · 74562-12291 · 74562-12300 · 74562-13030 · 74562-13041 · 74562-13060 · 74562-13061 · 74562-13070 · 74562-14270 · 74562-14320 · 74562-14330 · 74562-16030 |
| 74563 | Emission control equipment identification plate | 74563-11010 · 74563-20150 |
| 74571 | Brake fluid warning plate | 47288-32010 · 74571-22011 · 74571-27011 · 74571-27021 · 74571-27022 |
| 74579 | Unleaded fuel warning nameplate | 74579-30011 |
