Toyota COROLLA 警示铭牌(车外和车内) — Figure 7403
Toyota COROLLA EPC diagram 7403, 警示铭牌(车外和车内), with 1 images and 9 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 74518 | Maintenance warning nameplate | 74517-32010 · 74518-32010 |
| 74541 | tire pressure warning plate | 42661-12550 · 42661-12551 · 42661-12630 |
| 74541B | Small spare tire warning plate | 42668-40010 |
| 74541C | Out of air tire warning plate | 42661-12640 · 42661-12750 |
| 74559A | Fuel warning plate | 74559-14010 |
| 74562 | Emission control system information plate | 74562-12300 · 74562-12301 · 74562-12302 · 74562-12360 · 74562-12370 · 74562-20390 |
| 74563 | Emission control equipment identification plate | 74563-12130 · 74563-14130 |
| 74571 | Brake fluid warning plate | 47288-32010 · 74571-27021 · 74571-27022 |
| 74579 | Unleaded fuel warning nameplate | 74579-30011 |
