Toyota COROLLA 车内灯 — Figure 8121
Toyota COROLLA EPC diagram 8121, 车内灯, with 1 images and 14 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 81240B | Interior light bulb No. 1 | 90981-14011 |
| 81250 | No. 2 interior light assembly | 81250-48010 · 81330-58010 |
| 81250B | Interior light bulb No. 2 | 99132-12050 · 99132-13050 |
| 81260C | Light bulb (for reading lamp) | 90981-11062 |
| 81265C | No. 1 reading lamp shade | 81265-52020 |
| 81266D | Reading lamp shade No. 2 | 81266-52020 |
| 81310B | Rear interior light bulb | 90981-11062 |
| 81362B | Car interior lighting lampshade | 81362-12020 |
| 81366C | Interior light switch base | 81366-68010 |
| 81397A | Right interior light fixture | 81397-12020 |
| 81870D | Lock core lighting assembly | 81870-42020 |
| 81870E | Lock cylinder lighting bulb | 90010-01030 |
| 81936C | Bulb assembly | 81936-12150 |
| 84999E | Lock cylinder lighting bulb | 84999-10250 |
