Toyota COROLLA 后保险杠及附件 — Figure 5202
Toyota COROLLA EPC diagram 5202, 后保险杠及附件, with 1 images and 12 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 52169B | Rear bumper center bracket | 52169-13020 |
| 52185B | Installation support on the right side of the rear bumper | 52185-13040 · 52185-13050 |
| 52186B | Rear bumper left side mounting support | 52185-13040 · 52185-13050 |
| 52187B | Rear bumper positioning guide rod | 52187-16070 |
| 52552 | Arc filler on the right side of the rear bumper | 52552-13030 |
| 52553 | Rear bumper left curved filler | 52553-13030 |
| 52562 | Rear bumper upper side fixing bracket | 52562-12020 |
| 52591 | Rear bumper right seal | 52591-13020 · 52591-13030 |
| 52592 | Rear bumper left seal | 52592-13020 · 52592-13030 |
| 52752 | Rear bumper right side protective strip | 52752-13010 |
| 52753 | Rear bumper left protective strip | 52753-13010 |
| 52791 | Bumper protection strip No. 1 fixing bolt | 52791-12010 |
