Toyota COROLLA Engine Oil Cooler — Figure 1503

Toyota COROLLA EPC diagram 1503, Engine Oil Cooler, with 1 images and 3 PNC and OE references.

Toyota COROLLA Engine Oil Cooler EPC diagram — 151944C
Engine Oil Cooler — 151944C (201204 – 999999)

PNC and OE references

PNCPart nameOE numbers
15771No. 1 oil pipe15771-21010
15771EJoint bolt (for oil pipe)90401-12009 · 90401-12037
15771Gpadding90430-12037
