Toyota COROLLA 警示铭牌(车外和车内) — Figure 7403
Toyota COROLLA EPC diagram 7403, 警示铭牌(车外和车内), with 3 images and 26 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 11296C | Engine maintenance information label | 11296-21021 · 11296-21031 · 11296-37010 |
| 16793E | Toyota part | 16793-46010 |
| 41992 | Differential attention label | 41992-33010 |
| 69339C | Child Restraint Information Label | 69339-12010 · 69339-33040 |
| 74511B | Nameplate | 74511-2B300 |
| 74512A | Identification number plate | 74512-12010 · 74512-12011 · 74512-12020 · 74512-12021 · 74512-12030 · 74512-12031 · 74512-12040 · 74512-12041 · 74512-12050 · 74512-12060 · 74512-12070 · 74512-12080 · 74512-12090 · 74512-12100 · 74512-12110 · 74512-12120 · 74512-12130 · 74512-12140 · 74512-12150 · 74512-12160 · 74512-43010 |
| 74541 | tire pressure warning plate | 42661-12D20 · 42661-12D30 · 42661-12D40 · 42661-12D50 · 42661-12D80 · 42661-12E60 · 42661-12E80 · 42661-12G20 · 42661-12G30 |
| 74541B | Small spare tire warning plate | 42668-28060 |
| 74541E | Small spare tire warning plate | 42668-20030 |
| 74543J | rear seat warning label | 74543-13250 |
| 74543P | rear seat warning label | 74543-12050 |
| 74561A | fuel consumption information label | 74561-28010 · 74561-28020 · 74561-52010 · 74561-52020 · 74561-52030 · 74561-52040 |
| 74562B | Emission information label | 74562-47010 |
| 74571A | Label cover protective film | 74571-43010 |
| 86793B | Reversing camera information label | 86793-52010 |
| 87529B | Cabin filter information label | 87529-50020 |
| 88723E | Cooler maintenance warning label | 88733-52020 |
| 89176A | Air bag deployment information label | 89176-32010 |
| 89616 | Button start information label | 89616-52010 · 89616-52020 |
| C6111 | Safety warning nameplate | C6111-12010 |
| C6111A | Safety warning nameplate | C6111-22050 |
| C6112 | Safety Information Label No. 2 | C6112-D1170 |
| C6161 | Electric Lift Warning Label | C6161-12020 |
| C6162 | No. 2 Electric Lift Warning Label | C6162-18010 · C6165-12010 |
| C6184 | Front seat warning label | C6184-22030 |
| C6248 | Body number label | C6248-D1170 |
