Toyota COROLLA 扶手和遮阳板 — Figure 7401
Toyota COROLLA EPC diagram 7401, 扶手和遮阳板, with 2 images and 5 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 74231 | Right front armrest upper panel | 74231-12270 |
| 74232 | Left front armrest upper panel | 74232-12210 |
| 74271A | Right rear door armrest upper panel | 84656-12030 |
| 74272A | Left rear door armrest upper panel | 84656-12030 |
| 74619A | Auxiliary handle cushion | 74619-12020 |
