Toyota COROLLA 倒车灯 — Figure 8112
Toyota COROLLA EPC diagram 8112, 倒车灯, with 1 images and 6 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 81670B | Bulb (for reversing lights) | 90981-11039 · 90981-11059 |
| 81671 | Right reversing light cover | 81671-13040 |
| 81672 | Right reversing light cover gasket | 81672-13040 |
| 81675 | Reversing light holder and wiring harness | 81675-13040 |
| 81681 | Left reversing light cover | 81681-13010 |
| 81682 | Left reversing light cover gasket | 81682-13010 |
