Toyota COROLLA 警示铭牌(车外和车内) — Figure 7403
Toyota COROLLA EPC diagram 7403, 警示铭牌(车外和车内), with 1 images and 10 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 41992 | Differential attention label | 41992-33010 |
| 45197A | air bag warning label | 45197-20050 |
| 74541B | Small spare tire warning plate | 42668-32010 |
| 74541G | Safety warning nameplate | 42661-16520 · 42661-16521 · 42661-16530 · 42661-16531 · 42661-16540 · 42661-16541 |
| 74559A | Fuel warning plate | 74559-14030 |
| 74562 | Emission control system information plate | 11296-55030 · 11296-55031 · 74562-16280 · 74562-16300 · 74562-16310 |
| 74563 | Emission control equipment identification plate | 74563-10070 · 74563-16030 · 74563-16040 · 74563-46010 |
| 74751 | tire pressure information label | 42661-16630 · 42661-16640 · 42661-16690 · 42661-16700 · 42661-16710 |
| 75341C | engine cover plate | 75341-20060 |
| 89176A | Air bag deployment information label | 89176-51010 |
