Toyota COROLLA Ventilation Hose — Figure 1201

Toyota COROLLA EPC diagram 1201, Ventilation Hose, with 2 images and 7 PNC and OE references.

Toyota COROLLA Ventilation Hose EPC diagram — 120103
Ventilation Hose — 120103 (199409 – 999999)
Toyota COROLLA Ventilation Hose EPC diagram — NA0625A
Ventilation Hose — NA0625A (199409 – 999999)

PNC and OE references

PNCPart nameOE numbers
12204Ventilation valve sub-assembly12204-10030 · 12204-10040 · 12204-11040
12204AGasket (for ventilation system)90480-18006
12261Ventilation Hose12261-11180 · 12261-55030
12261AClip or clip (for vent hose)90467-15021
12261BClip or clip (for vent hose)90467-15021
12262Ventilation hose No. 212262-11050
12262AClamp (for vent hose No. 2)90467-14001 · 90467-14043
