Toyota COROLLA 警示铭牌(车外和车内) — Figure 7403
Toyota COROLLA EPC diagram 7403, 警示铭牌(车外和车内), with 1 images and 8 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 45197A | air bag warning label | 45197-20050 |
| 74541 | tire pressure warning plate | 42661-16310 · 42661-16311 · 42661-16320 · 42661-16350 · 42661-16351 · 42661-16360 · 42661-16370 · 42661-16380 · 42661-16390 · 42661-16400 · 42661-16401 · 42661-16410 · 42661-16420 · 42661-16430 |
| 74541E | Small spare tire warning plate | 42668-32010 |
| 74559A | Fuel warning plate | 74559-14030 |
| 74562 | Emission control system information plate | 74562-10180 · 74562-10210 · 74562-16230 · 74562-16240 · 74562-16250 · 74562-16260 · 74562-16270 |
| 74571 | Brake fluid warning plate | 47288-32010 |
| 74579A | Unleaded Fuel Information Label | 74579-30011 |
| 75341C | engine cover plate | 75341-20060 |
