Toyota COROLLA 警示铭牌和名称铭牌(发动机) — Figure 1709
Toyota COROLLA EPC diagram 1709, 警示铭牌和名称铭牌(发动机), with 1 images and 7 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 11284 | Engine bolt information plate | 11284-55030 |
| 11291 | Engine name plate | 11292-11060 · 11292-11080 · 11292-11100 |
| 11292 | Engine No. 2 name plate | 11292-55010 |
| 11294 | Engine No. 2 warning plate | 11294-55010 |
| 11296 | Timing belt warning plate | 17791-11080 · 17791-15010 · 17791-55010 |
| 11296A | Engine maintenance information label | 11296-11181 · 11296-11182 · 11296-11210 · 11296-11211 · 11296-11220 · 11296-11221 |
| 17791 | Maintenance information label | 11296-55010 |
