Toyota COROLLA 锁芯组件 — Figure 6712
Toyota COROLLA EPC diagram 6712, 锁芯组件, with 1 images and 6 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 69503 | Door lock cylinder components | 69005-0A020 |
| 69503A | external tooth key | 69515-16110 |
| 69503B | internal tooth key | 69515-0A010 |
| 89072B | Remote key shell assembly (for smart key) | 89072-0A030 · 89072-0A060 · 89072-0A070 |
| 89745C | Transmitter battery | 89745-0K010 |
| 89904B | Electronic key transmitter sub-assembly | 8990H-0A040 · 8990H-0A050 · 8990H-0A060 |
