Toyota COROLLA Spare tire rack — Figure 5104
Toyota COROLLA EPC diagram 5104, Spare tire rack, with 3 images and 5 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 51900 | Spare tire rack assembly | 51900-12050 · 51900-12060 · 51900-12070 · 51900-13140 · 51900-13150 · 51900-17020 · 51931-12010 · 51931-12020 |
| 51938 | Spare tire rack lock | 51938-13040 · 51938-13050 |
| 51938D | Conduit (for spare wheel carrier bolt) | 90440-17060 · 90440-17061 |
| 51938F | Bolt (for spare tire carrier lock) | 90119-12181 · 90119-12184 |
| 64777E | Spare tire cover clip | 64777-12010 · 64777-12020 |
