Toyota COROLLA 警示铭牌(车外和车内) — Figure 7403
Toyota COROLLA EPC diagram 7403, 警示铭牌(车外和车内), with 2 images and 12 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 11296C | Engine maintenance information label | 11296-0D040 · 11296-27020 |
| 16595E | Radiator cap warning label | 16595-50010 |
| 16793E | Cooling fan warning label | 16793-0D010 · 16793-11010 · 16793-15020 |
| 47288 | Brake Fluid Caution Label | 47288-60010 |
| 69339C | Child Restraint Information Label | 69339-06030 · 69339-06080 · 69339-52020 |
| 74541 | tire pressure warning plate | 42661-02B80 · 42661-12A40 |
| 74571 | Brake fluid warning plate | 47287-02010 · 47287-12010 |
| 74579A | Unleaded Fuel Information Label | 74579-0D010 · 74579-26010 · 74579-26011 |
| 74598A | Passenger air bag warning label | 74598-06040 · 74598-20010 |
| 87528 | Air conditioner information label | 87528-02010 |
| 87529B | Cabin filter information label | 87529-0D020 |
| 88723E | Cooler maintenance warning label | 88723-0D020 |
