Toyota COROLLA 警示铭牌和名称铭牌(发动机) — Figure 1709
Toyota COROLLA EPC diagram 1709, 警示铭牌和名称铭牌(发动机), with 1 images and 8 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 11275 | Adjust ignition timing warning nameplate | 11275-16010 · 11275-16011 |
| 11278 | Engine emission identification plate | 11278-16020 |
| 11288 | Engine system nameplate | 11288-88301 |
| 11289 | Spark plug warning nameplate | 11289-13040 · 11289-73020 |
| 11291 | Engine name plate | 11291-16020 · 11291-16021 · 11291-16040 |
| 11298 | Emission control information plate | 11298-16040 · 11298-16050 · 11298-16051 · 11298-16052 · 11298-16080 · 11298-16081 · 11298-16230 · 11298-16320 · 11298-16430 |
| 17700D | Engine warning plate | 11293-14030 · 11293-16030 |
| 17792 | Engine vacuum hose information plate | 17792-12030 · 17792-12031 · 17792-12040 · 17792-16020 |
