Toyota COROLLA 侧防护条 — Figure 7503
Toyota COROLLA EPC diagram 7503, 侧防护条, with 1 images and 24 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 60117 | Right front pillar upper cover sub-assembly | 60117-0F010 |
| 60118 | Left front pillar upper cover sub-assembly | 60118-0F010 |
| 67771C | Front pillar cover fixing parts | 67772-95J03 |
| 67865J | Right front door seal No. 3 | 67865-0F010 |
| 67866H | Left front door No. 3 sealing strip | 67866-0F010 |
| 67887F | Right rear door seal No. 2 | 67887-0F010 |
| 67888D | Left rear door seal No. 2 | 67888-0F010 |
| 75555D | Drainage channel side decorative strip in the middle section on the right side of the roof | 75555-0F010 |
| 75556C | Drainage channel side decorative strip in the middle section on the left side of the roof | 75556-0F010 |
| 75561 | No. 1 roof drain channel side decorative strip clip | 75561-33030 |
| 75707 | Right rear door window frame protective strip sub-assembly | 75707-0F010 |
| 75708 | Left rear door window frame protective strip sub-assembly | 75708-0F010 |
| 75710 | Right front door waistline protection strip assembly | 75710-64010 |
| 75720 | Left front door waistline protection strip assembly | 75720-64010 |
| 75730 | Right rear door waistline protection strip assembly | 75730-64010 |
| 75740 | Left rear door waistline protection strip assembly | 75740-64010 |
| 75755C | Right front door window frame rear protective strip | 75755-0F010 |
| 75756C | Left front door window frame rear protective strip | 75756-0F010 |
| 75851 | Right side door sill panel protective strip | 75851-0F010 |
| 75852 | Left side door sill panel protective strip | 75852-0F010 |
| 75867A | Door sill panel protective strip clip | 52161-0F010 |
| 75868B | No. 2 door sill plate protective strip clip | 75868-33020 |
| 76915H | Right front fender | 76915-0F010 |
| 76916H | Left front fender | 76916-0F010 |
