Toyota COROLLA 背门锁和背门把手 — Figure 6709
Toyota COROLLA EPC diagram 6709, 背门锁和背门把手, with 1 images and 9 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 68810C | Back door right hinge assembly | 68810-02020 · 68810-21050 |
| 68820C | Back door left hinge assembly | 68810-02020 · 68810-21050 |
| 68945 | Back door right damping stay upper bracket | 68945-64010 |
| 68946 | Rear door left damping strut upper bracket | 68946-64010 |
| 68950C | Back door right support rod assembly | 68950-0F010 · 68950-0F011 · 68950-0F012 |
| 68960 | Back door left support rod assembly | 68960-0F010 · 68960-0F011 · 68960-0F012 |
| 68961 | Rear door support rod bolts | 68961-05010 |
| 69350P | ENS. VERR, HAYON, AV COMM PLAFONNIER | 69350-05030 · 69350-05031 · 69350-05050 · 69350-05051 |
| 69430A | Back door lower lock assembly | 69430-20160 |
