Toyota COROLLA 警示铭牌(车外和车内) — Figure 7403
Toyota COROLLA EPC diagram 7403, 警示铭牌(车外和车内), with 2 images and 13 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 11285A | Coolant System Caution Labels | 11285-0G010 · 11285-27030 |
| 11296C | Engine maintenance information label | 11296-27020 |
| 69339C | Child Restraint Information Label | 69339-02030 |
| 73794 | Rear seat belt caution label | 73794-02020 |
| 74515A | Anti-theft warning nameplate | 74515-0D010 · 74515-47010 |
| 74559B | fuel information label | 74559-02010 · 74559-05010 |
| 74567A | E.C.E approval number plate | 74567-20261 · 74567-26201 · 74567-26250 |
| 74596A | Side air bag warning label | 74596-12020 |
| 74598A | Passenger air bag warning label | 74598-02050 · 74598-0F010 |
| 74751 | tire pressure information label | 42661-02240 · 42661-02260 · 42661-02270 · 42661-02280 · 42661-02370 |
| 87529B | Cabin filter information label | 87529-0D010 |
| 88723E | Cooler maintenance warning label | 88723-12140 · 88723-28220 · 88733-12030 |
| C6177 | Heater Caution Label | C6177-05010 |
