Toyota COROLLA 警示铭牌(车外和车内) — Figure 7403
Toyota COROLLA EPC diagram 7403, 警示铭牌(车外和车内), with 2 images and 17 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 11285A | Coolant System Caution Labels | 11285-27030 |
| 11296C | Engine maintenance information label | 11296-22090 · 11296-27020 |
| 13564 | ETIQUETTE, INFO REMPLACEMENT COURROIE DISTRIBUTION | 13564-10010 |
| 16793E | ETIQUETTE, PRECAUTION VENT REFROIDISSEMENT | 16793-11010 · 16793-46010 |
| 69339C | Child Restraint Information Label | 69339-12010 |
| 73794 | Rear seat belt caution label | 73794-33010 |
| 74511F | Nameplate (laser identification label) | 74511-48010 · 74511-48020 · 74511-48050 |
| 74515A | Anti-theft warning nameplate | 74515-52010 |
| 74541 | tire pressure warning plate | 42661-1E200 · 42661-1E210 · 42661-1E220 · 42661-1E270 |
| 74559A | Fuel warning plate | 74559-14030 · 74559-14050 |
| 74567A | E.C.E approval number plate | 74567-20261 · 74567-26201 |
| 74571 | Brake fluid warning plate | 47287-12010 |
| 74579A | Unleaded Fuel Information Label | 74579-33010 |
| 74596A | Side air bag warning label | 74596-12020 · 74596-12030 |
| 87529B | Cabin filter information label | 87529-50010 |
| 88723E | Cooler maintenance warning label | 88723-28220 · 88733-12030 |
| C6177 | Heater Caution Label | C6177-05010 |
