Toyota CAMRY Floor stringers — Figure 5305
Toyota CAMRY EPC diagram 5305, Floor stringers, with 1 images and 38 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 53704D | Battery left side bracket sub-assembly | 53704-06010 · 53704-06030 · 53704-08020 · 53704-08021 · 53704-33020 |
| 57101 | Right front longitudinal beam sub-assembly | 57101-06050 |
| 57102 | Left front longitudinal beam sub-assembly | 57102-06060 · 57102-06061 |
| 57103A | Floor No. 3 beam sub-assembly | 57103-06020 · 57103-07010 · 57103-07011 |
| 57105 | Right front suspension cross member front mounting bracket sub-assembly | 57105-06010 |
| 57106E | Left front suspension cross member front mounting bracket sub-assembly | 57106-06010 |
| 57111 | Right front longitudinal beam | 57111-06020 |
| 57112 | Left front longitudinal beam | 57112-06030 |
| 57113 | Right front longitudinal beam extension | 57107-06010 |
| 57114 | Left front longitudinal beam extension | 57108-06010 |
| 57115A | Right front longitudinal beam outer panel | 57115-06030 |
| 57116A | Left front longitudinal beam outer panel | 57116-06020 |
| 57117B | Install reinforcement on the right side of the front bumper | 57117-06030 |
| 57118A | Install reinforcement on the left side of the front bumper | 57118-06030 |
| 57151A | No. 1 right front longitudinal beam reinforcement | 57151-06010 |
| 57152 | No. 1 left front longitudinal beam reinforcement | 57152-06010 |
| 57155 | No. 3 right front longitudinal beam reinforcement | 57155-06010 |
| 57156 | No. 3 left front longitudinal beam reinforcement | 57156-06010 |
| 57167E | Front cross member right corner panel | 57167-06010 |
| 57168E | Front cross member left corner panel | 57168-06010 |
| 57197 | Right front torsion box section piece | 57077-06040 |
| 57198 | Left front anti-torsion box section piece | 57078-06040 |
| 57249 | No. 1 Flexible Hose Bracket | 57249-06010 |
| 57249A | No. 1 Left Flexible Hose Bracket | 57249-06010 |
| 57401 | Main floor right longitudinal beam sub-assembly | 57401-06090 |
| 57402 | Main floor left longitudinal beam sub-assembly | 57402-06090 |
| 57417 | Front floor lower right reinforcement | 57419-06030 |
| 57418 | Front floor lower left reinforcement | 57419-06030 |
| 57451B | Front floor right cross member | 57451-06050 · 57451-06902 |
| 57452 | Front floor left cross member | 57452-06020 · 57452-06900 |
| 57601 | Rear floor right longitudinal beam sub-assembly | 57601-06150 · 57601-06151 |
| 57602 | Rear floor left longitudinal beam sub-assembly | 57602-06090 |
| 57605B | Rear floor No. 1 cross member sub-assembly | 57605-06050 |
| 57606C | Rear floor No. 2 cross member sub-assembly | 57606-06040 · 57606-06110 · 57606-07010 |
| 57611A | Rear floor right longitudinal beam | 57611-06906 |
| 57612A | Rear floor left longitudinal beam | 57612-06906 |
| 57615A | Rear floor right rear longitudinal member | 57615-06901 · 57615-06902 |
| 57616A | Rear floor left rear longitudinal member | 57616-06903 |
