Toyota CAMRY Floor stringers — Figure 5305
Toyota CAMRY EPC diagram 5305, Floor stringers, with 1 images and 33 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 53704D | Battery left side bracket sub-assembly | 53704-06020 |
| 57077 | Right front anti-torsion box-section sub-assembly | 57077-06060 |
| 57078A | Left front anti-torsion box-section sub-assembly | 57078-06060 |
| 57101 | Right front longitudinal beam sub-assembly | 57101-06080 |
| 57102 | Left front longitudinal beam sub-assembly | 57102-06080 |
| 57103A | Floor No. 3 beam sub-assembly | 57103-06030 |
| 57105 | Right front suspension cross member front mounting bracket sub-assembly | 57105-06020 |
| 57106E | Left front suspension cross member front mounting bracket sub-assembly | 57106-06020 |
| 57111 | Right front longitudinal beam | 57111-YC012 |
| 57112 | Left front longitudinal beam | 57112-YC012 |
| 57113 | Right front longitudinal beam extension | 57113-06040 |
| 57114 | Left front longitudinal beam extension | 57114-06040 |
| 57115A | Right front longitudinal beam outer panel | 57115-YC010 |
| 57116A | Left front longitudinal beam outer panel | 57116-YC010 |
| 57117B | Install reinforcement on the right side of the front bumper | 57033-YC011 |
| 57118A | Install reinforcement on the left side of the front bumper | 57034-YC011 |
| 57185 | No. 1 right front longitudinal beam inner rear reinforcement | 57185-06010 |
| 57401 | Main floor right longitudinal beam sub-assembly | 57401-06110 |
| 57402 | Main floor left longitudinal beam sub-assembly | 57402-06110 |
| 57417 | Front floor lower right reinforcement | 57419-06050 |
| 57418 | Front floor lower left reinforcement | 57419-06050 |
| 57423B | Right inner reinforcement under front floor | 57423-YF010 |
| 57424B | Left inner reinforcement under front floor | 57423-YF010 |
| 57451 | front floor cross member | 57451-06070 |
| 57468D | Front right seat outer rear bracket | 57468-YC020 |
| 57469C | Front left seat outer rear bracket | 57469-YC020 |
| 57601 | Rear floor right longitudinal beam sub-assembly | 57601-06170 |
| 57602 | Rear floor left longitudinal beam sub-assembly | 57602-06120 |
| 57605B | Rear floor No. 1 cross member sub-assembly | 57605-06060 |
| 57606C | Rear floor No. 2 cross member sub-assembly | 57606-06050 · 57606-06051 |
| 57615A | Rear floor right rear longitudinal member | 57615-06905 · 57615-06912 |
| 57616A | Rear floor left rear longitudinal member | 57616-06907 · 57616-06909 · 57616-06915 |
| 58252A | rear floor bracket | 58252-33010 |
